Specifications

Body

• Body Material: PLAIN OR VERY LIGHT FIGURED A/MAH
• Routing: 59 LES PAUL-CARMELITA TILTED
• Drilling: 59 LES PAUL
• Dimension: 59 LES PAUL
• Top: PLAIN OR VERY LIGHT FIGURED A 2PC
• Back: MAHO 1PC LIGHT
• Rim: HIDE GLUE
• Body Top Binding: .09 CREAM
• Fingerboard Binding: .04 CREAM
• Other: TORT SIDE DOTS
• Finish: Ebony Heavy Aged
• Decal(s): MURPHY LAB CHECKED LACQUER, 2 COATS TH ANTIQUE

Neck

• Neck Material: MAHOGANY
• Peghead: REISSUE
• Head Veneer: REISSUE
• Dimensions: CARMELITA FINE CARVED-DO NOT ROLL
• Fretboard Material: 2019 INDIAN ROSEWOOD 1PC
• Scale: 24 3/4
• Dimension: STD
• Nut: NYLON
• Inlays: REISSUE with NEW MATERIAL
• Fretwire: REISSUE

Hardware

• Hardware Material: NICKEL HEAVY AGED
• Machine Head: KLUSON REISSUE - AGED BUTTONS
• Bridge: ABR-1 NON WIRE
• Tailpiece: LIGHT WEIGHT w/LONG STUD, ANCHOR
• Jackplate: TRUE HISTORIC REISSUE
• End Pin: AL
• Truss Cover: TRUE HISTORIC FROM ADVANCED
• Pickguard: TRUE HISTORIC R9
• Knobs: TRUE HISTORIC GOLD TOP HATS
• Mounting Rings: TRUE HISTORIC CREAM
• Switch Tip: TRUE HISTORIC AMBER
• Backplates: CS MEDALLION REISSUE IN CASE
• Other: TRUE HISTORIC CREAM SWITCH WASHER

Electronics

• Pickup(s): CSTBUCKER UNPOTTED NPC TH MCMR
• CSTBUCKER UNPOTTED NPC TH XHCMR
• Circuitry: TH COVERS AND RINGS
• Other: 2019 CPA (PIO CAPS, VINT TAPER POTS)
